Characteristic uses of enameled wire

Views: 0     Author: Site Editor     Publish Time: 2020-07-30      Origin: Site

Inquire

facebook sharing button
twitter sharing button
line sharing button
wechat sharing button
linkedin sharing button
pinterest sharing button
whatsapp sharing button
kakao sharing button
snapchat sharing button
telegram sharing button
sharethis sharing button

1. Acetal enameled wire with two thermal grades: 105 and 120. It has good mechanical strength, adhesion, resistance to transformer oil and refrigerant, but the product has poor moisture resistance, low thermal softening breakdown temperature, and durable benzene-alcohol mixed solvent Weak performance and other defects, only a small amount is used in the windings of oil-immersed transformers and oil-filled motors.

2. For polyester and modified polyester enameled wires, the thermal class of ordinary polyester enameled wire is 130, and the thermal class of enameled wire after modification is 155. The product has high mechanical strength, good elasticity, adhesion, electrical properties and solvent resistance. The weakness is poor thermal shock resistance and low moisture resistance. It is currently the largest product in my country, accounting for about two-thirds, and is widely used in various motors, electrical appliances, meters, telecommunications equipment and home appliances.

3. Polyurethane enameled wire; thermal grade is 130, 155, 180, 200. The biggest feature is that it has direct solderability, good high frequency resistance, easy coloring, and good moisture resistance. It is widely used in electronic appliances, precision instruments, telecommunications, and meters. The weakness of this product is that the mechanical strength is slightly poor, and the heat resistance is not high. , And the flexibility and adhesion of the production of large-size wires are poor, so the specifications of this product are small and fine wires.

4. Polyesterimide/polyamide composite enameled wire, thermal class 180. This product has good thermal shock resistance, high softening and breakdown temperature, excellent mechanical strength, good solvent and refrigerant resistance, and the weakness is that it is easy to Hydrolysis is widely used in windings of motors, electrical appliances, meters, power tools, and dry-type power transformers that require high heat resistance.

5. Polyesterimide/polyamideimide composite layer enameled wire is a heat-resistant enameled wire widely used at home and abroad. Its thermal class is 200. This product has high heat resistance and is also resistant to refrigerants, cold, and radiation. Features, high mechanical strength, stable electrical performance, good chemical resistance and refrigerant resistance, and strong overload capacity. It is widely used in refrigerator compressors, air-conditioning compressors, electric tools, explosion-proof motors and motors and electrical appliances used under high temperature, high cold, radiation resistance, and overload conditions.
